VAXserver/MicroVAX 3500/3800 Conversion
2.4 Installing the Kit
34. Attach the new logo model label over the existing logo model label as shown
in Figure 2–8 for rack-mountable systems.
35. Attach the new conversion label as shown in Figure 2–7 for pedestal
systems, and Figure 2–8 for rack-mountable systems.
Figure 2–8 Label Locations on System Without Panels
MLO-003960
LJ-00533-TI0
Existing
Logo/Model
Label
Conversion
Label
Product Conversion Label
From:
To:
By: Date:
36-15846-01-C1
VAXserver/MicroVAX 3500/3800 Conversion 2–13
