VAXserver/MicroVAX 3500/3800
Conversion
This chapter describes how to convert from a VAXserver 3500/3800 system to a
VAXserver 4000-200 system and from a MicroVAX 3500/3800 system to a VAX
4000-200 system using a 660XR-XX conversion kit.
Caution
The MS650–AA memory module will not function with a KA660–XX
CPU module. When a KA650 or KA655 CPU module is removed and
the system is converted to a KA660-XX system, do the following:
1. Install an MS650–BA (16-Mbyte) memory or MS650–BB (8-Mbyte)
memory module.
2. Remove the H3600 CPU I/O panel and install the H3602 I/O panel.
The H3602 panel is included in the conversion kit.
2.1 Summary of Conversion
The tasks required to convert from a VAXserver 3500/3800 system to a
VAXserver 4000-200 system and from a MicroVAX 3500/3800 system to a VAX
4000-200 system are summarized as follows. To begin the actual conversion, go
to Section 2.2.
1. Have the customer back up the system software.
2. Run diagnostics to verify system operation.
3. Unpack and verify the contents of the conversion kit.
4. Remove the front panel and media faceplate.
5. Remove the operator control panel (OCP).
