VAXserver/MicroVAX 3300/3400 Conversion
1.4 Installing the Kit
Note
Two labels are shipped with the conversion kit. Install the JTT label,
P/N 36-33180-18, for a BA213 enclosure; install the JTT label, P/N
36-33180-19, for a BA215 enclosure.
22. Attach the new logo model label over the existing logo model label as shown
in Figure 1–6 for rack-mountable systems.
23. Attach the conversion label, as shown in Figure 1–5 for a pedestal system,
and Figure 1–6 for a rack-mountable system.
Figure 1–6 Label Locations on System Without Panels
MLO-003960
MicroVAX 3400
LJ-00531-TI0
Existing
Logo/Model
Label
Conversion
Label
Product Conversion Label
From:
To:
By: Date:
36-15846-01-C1
JTT
LJ-02491-TI0
