VAXserver/MicroVAX 3300/3400 Conversion
1.4 Installing the Kit
4. Remove the console cable as shown in Figure 1–2.
5. If the Ethernet cable is present, remove the Ethernet cable from the I/O
panel.
Caution
Use the antistatic wrist strap and the antistatic mat when working
with the modules.
Figure 1–2 Removing Console Cable
MLO-002610
Console
Cable
Locking Tab
Squeeze Locking Tab
and Pull From Jack
VAXserver/MicroVAX 3300/3400 Conversion 1–5
