User guide

e
lectrical Safety
4
4. Electrical Safety
Before switching on, make sure that the voltage
of your electricity supply is the same as that
indicated on the rating plate. This product is
designed to operate on 220 – 240V AC, 50Hz.
Connection to any other power source may
damage the unit.
This product may be fitted with a non –
rewireable plug. If it is necessary to change the
fuse in the plug, the fuse cover must be refitted.
If the fuse cover becomes lost or damaged, the
plug must not be used until a suitable
replacement obtained.
If the plug has to be changed because it is not
suitable for your socket, or becomes damaged
in any way, it should be cut off and an
appropriate plug fitted following the wiring
instructions below. This should be carried out by
a qualified electrician. The plug removed must
be disposed of safely, as insertion into a 13 Amp
socket is likely to cause an electrical hazard.
IMPORTANT – THIS IS A CLASS II
APPLIANCE AND DOES NOT REQUIRE
AN EARTH CONNECTION.
Wiring Instructions
The wires in this mains lead are colored in
accordance with the following code:
Blue = Neutral Brown = Live
As the colours of the wires in the mains lead of
this appliance may not correspond with the
coloured markings identifying the terminals in
your plug, proceed as follows (refer to the plug
wiring diagram).
• The wire which is coloured BLUE must be
connected to the terminal which is marked
with the letter N or coloured Black.
• The wire which is coloured BROWN must
be connected to the terminal which is
marked with the letter L or coloured Red.
If a 13Amp (BS1363) plug is used, a 13Amp
(BS1362) fuse must be fitted, or if any other type
of plug is used, a 13Amp fuse must be fitted,
either in the plug or adaptor, or on the
Distribution Board.
!
