V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:35 Page 2 Guarantee / Technical Specification 1. Guarantee 2. Technical Specification This product is guaranteed for 1 year from the date of original purchase. Power supply: If any defect arises due to faulty materials or workmanship, the unit will, either be repaired, replaced or refunded at our discretion. The following conditions apply: • The product must be returned to the retailer with original proof of purchase.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:35 Page 3 Safety Information 3. Safety Information FOR HOUSEHOLD USE ONLY. When using the vacuum cleaner, basic safety precautions should always be observed, including the following: 1. Only use the vacuum cleaner indoors on dry surfaces. 2. Turn off the vacuum cleaner controls before connecting to or disconnecting from the mains supply. 3. Always unplug the vacuum cleaner before connecting or disconnecting the vacuum hose. 4.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:35 Page 4 electrical Safety 4. Electrical Safety Wiring Instructions Before switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 220 – 240V AC, 50Hz. Connection to any other power source may damage the unit.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:36 Page 5 Assembly 5. Assembly Assembly of the Hose IMPORTANT: Always remove the power plug from the electrical outlet before assembling or removing accessories. 4. Align the tabs on the lower hose/inspection tube with the slots on the hose. Push and turn the hose clockwise until secure (Fig.5/4). ! Handle Assembly 1. Firmly push the back panel onto the base assembly.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:36 Page 6 Operation 6. Operation 1. Turn the vacuum cleaner on by pressing the on/off switch located on the lower right side of the cleaner (Fig.6/1). The cleaner can be turned off by pressing the on/off switch again. Fig.6/3 On/off switch WARNING: To avoid injury, keep loose clothing, hair, fingers and all other parts of the body away from any moving part (such as the brushbar).
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:36 Page 7 Dirt Container & Filter 7. Dirt Container & Filter: Removal and Replacement IMPORTANT: Always unplug the unit from the electrical outlet before opening the dirt container. ! ! IMPORTANT: Do NOT use the vacuum without the HEPA filter in place. To remove the dirt container, press the dirt container release button and lift away from the vacuum cleaner (Fig 7/1). The HEPA filter may be washed by running it under the tap.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:36 Page 8 Maintenance 8. Maintenance Cleaning and Changing the Belt Tools required: Phillips screwdriver. WARNING: To reduce the risk of electric shock, the power cord must be disconnected before removing the dirt container, HEPA filter, changing the filters or performing maintenance / troubleshooting checks. Occasionally, the power nozzle drive belt will require changing, the frequency will depend upon the amount of vacuum use. ! 1.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:36 Page 9 Troubleshooting ! ! 9.! Troubleshooting ! WARNING: To reduce risk of personal injury unplug vacuum cleaner before servicing PROBLEM: Cleaner won’t run Cause: Not properly plugged into electrical outlet. Solution: Plug cord in firmly. Cause: No electricity in wall outlet. Solution: Check fuse or breaker. Cause: On/off switch not turned on. Solution: Push on/off switch to on. Cause: Motor thermostat tripped.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:36 Page 10 Service 10. Service 11. Spare Parts List • If the power cord has been damaged in any way, do not use the vacuum cleaner. The vacuum cleaner must be repaired by a qualified service agent. JMU4010 /01 Hose JMU4010 /02 Drive Belt JMU4010 /03 Beater Bar If you have any technical problems with your vacuum cleaner, please call the JMB helpline: 01733 404703.
V-044LW (JMB) User Guide.qxd:JMB JMU4010 User Guide 18/3/08 17:36 Page 11 Recycling 12. Waste Electrical Recycling This symbol indicates that this product is classed as Electrical or Electronic Equipment and should not be disposed of with other household waste.
