User guide

Insert the back
panel into the
oorhead.
The back panel will
click into place when
it slides into position
as highlighted.
Insert the screw into
the back panel near
the base, use a cross-
head screwdriver to
tighten securely
Assembling your upright
Wrap the power cord around the
quick release cord hook at the top
and the lower cord hook, continue
wrapping the power cord until it
is secure
Place the dirt container onto the
machine and push onto the back
panel to click into place
Clip hose into the hose
holders to secure
Align the post motor
lter tabs in position
and turn clockwise to
lock into place
Attach the turbo tool and
extension tube to the tool holders.
Attach the hose end with clip
to the handle and push until it’s
secure. Insert the other end of
hose into the slot on the rear of
machine, align the tabs and turn
until it locks into place
Insert handle
extension tube
into the top of the
machine and push
until it locks
into place
Getting started Using your machine
PLEASE READ ‘LEt’S tALk SAFEtY’ At tHE BEGINNING BEFORE USE
Place the post motor lter
onto the lter housing.
