OTHER CAPABILITIES

Google Play

ECTACO

SpeechGuard

TLX allows you to browse and download music,

magazines, books, movies, television programs, and applications that were

published through Google. If you don't have a Google account, you can also

create one.

Using the 2-Way Radio

Installing the 2-Way Radio Antenna

The 2-Way Radio function is designed to operate with an antenna. You must

install the antenna before using the 2-Way Radio. Do not install the antenna if you

only need GSM or CDMA cellular networking. The device is equipped with a built-

in antenna for this purpose.

 Open the antenna cover.

 Screw the antenna on the connector.

Setting up Parameters

 Launch the 2 Way Radio application.

 Select the check box in the top row to enable country selection.

 Tap the Area button and select your country or region.

 Tap the CH button and select a channel.

 Tap the CTCSS button and select one of the available levels. For example,

select 0.

 Tap the SQ button and select a noise cancelation level. It is recommended

that you select 1.

 Tap the OK button to save settings.

Note: Make sure the device of your interlocutor has the same 2 Way Radio

settings. To communicate, all radios in your group must be set to the same

channel and CTCSS code.

 Tap the Power On button to turn the radio on.

You can also configure the 2-Way Radio manually. To do this, select the check

box in the second row and then enter the frequency value manually. Below is an

example of settings.

 Set TFV and RFV frequencies to 462.7 MHz or any other frequency allowed

for this purpose in the host country.
