Datasheet

Data Sheet Lithium Manganese Dioxide CR 1/3 N
VARTA Consumer Batteries GmbH & Co. KGaA Subject to change without prior notice!
Alfred-Krupp-Str. 9, 73479 Ellwangen/Germany Date of issue: 2008-04-15
Phone: [phone], Fax: [phone]
Type Number............................ 6131
Designation IEC........................ CR 11108
System........................................ Li-Manganese dioxide/
Organic Electrolyte
UL Recognition.......................... MH 13654 (N)
Nominal Voltage........................ 3 V
Typical Capacity C................... 170 mAh
Load 5.6 kOhm, at 20°C down to 2 V
Weight (approx.)........................ 3 g
Volume........................................ 1,1 ccm
Coding......................................... TBA
Temperature Ranges min max.
Storage.......................................... -55°C 70°C
Discharge...................................... -20°C 65°C
Dimensions min max.
Diameter (A) ............................... 11,4 11,6
Height (B).................................... 10,4 10,8
Shoulder Diameter [E] 7,8
Shoulder Height [C] 0,4
Segment....................................... Electronic
Main Applications...................... Photo
Electronic
Typical Capacities (at 20°C)
Discharge Type Load End Voltage: 2.0V
Continuous 5600
Ω Time: [h]: 335
24h/d, 7d/w Capacity [mAh]: 170
Current [µA] Energy [MWh]: 475
All Data contained herein is for single cells
For battery applications, performance data may vary from single cell data, depending on specific battery configuration
