Datasheet

VH 1300 AA
Rechargeable Cylindrical Cells (NiMH)
Data Sheet
Date of Issue: 2012-08-17 Subject to change without prior notice !
VARTA Microbattery GmbH
Daimlerstraße 1, 73479 Ellwangen, Germany
Tel.: [phone]
Telefax: [phone]
Fo_171
Type Number
Designation IEC
System
UL Recognition
Nominal Voltage
Rated Capacity (0.2 C / 1.0 V)
Impedance AC at 1 kHz, fully charged
Typical Capacity at
0.2 C / 1.00 V
Max Discharge Current (cont. / 1.0 V)
Dimensions
Diameter (a)
Height (b)
Cap Diameter (d)
Weight, approx
Charge Conditions
Standard Charge
Fast Charge (charge termination control
recommended).
Control parameters
Trickle Charge (0.05 - 0.1 C)
Temperature Range
Storage 1 Year
(1
6 Month
1 Month
(1)
recharge every 6 months
Charge
Fast Charge
Discharge
55115
HR 15 / 49
NiMH
MH13654
1.2 V
1300 mAh
< 38 mOhm
1340 mAh
3900 mA
14.4
– 0.7
mm
48.2
– 1.0
mm
6.5 mm
25 g
130 mA / 16 h (t
max
)
650 mA to 1300 mA
(0.5 to 1 C)
-∆U = 0 – 5 mV
DT / dt = 0.8 °C / min (0.5 to 0.9 C)
0.8 °C – 1 °C / min (1 C)
Temp. cut-off = 45 – 50 °C
Timer: 105 % nominal input
65 - 130 mA
-20 °C - +25 °C
-20 °C - +35 °C
-20 °C - +45 °C
0 °C - 45 °C
10 °C - 45 °C
-20 °C - 50 °C
All Data contained herein is for single cells
For battery applications, performance data may vary from single cell data, depending on specific battery configuration
