Multifunction Internal Card Reader Support 59 Types of Memory Cards Fits In 5.25” Drive Bay SDHC Compatible Built-in eSATA / USB 2.
Package Contents : All in 1 Multifunction Internal Card Reader 1 2 3 All in 1 Multifunction Internal Card Reader Installation Screws User’s Manual 1 2 3 Multifunction Internal Card Reader Support 59 Types of Memory Cards Fits In 5.25” Drive Bay User’s Manual SDHC Compatible Built-in eSATA / USB 2.0 / FireWire Ports 5.25" Mounting Bracket Included ! USER’S MANUAL TRADEMARKS MS-DOS, Microsoft, Windows NT/2000/ME/XP/Vista are trademarks of Microsoft Corporation.
Table of Contents : 1. Introduction ............................................................................................................... 02 2. Features/Specifications..................................................................................03 3. System Requirements/Parts Layout .................................................04 4. Installation ...................................................................................................................05 5. FAQ/Warranty............
1. Introduction : From digital cameras to PDAs, data storage is a crucial piece to all these devices. Unfortunately, with so many different types of memory cards, accessing them can quickly turn your computer into a mess of wires and adapters. The Vantec All-in-1 Multifunction Internal Card Reader brings you a convenient and compact way to share and exchange files stored in your flash memory cards from one simple panel. In addition, with the extra eSATA, USB 2.
2. Features / Specifications : All in 1 Multifunction Internal Card Reader Features: • Read/Write to 59 Types of Memory Cards • No Adapter Required for Micro SD (T-flash) • Fits in Any Standard 5.25” Drive Bay • Simultaneously Transfer Data Between Memory Cards • Two eSATA / Two USB2.0 / FireWire Ports • Transfer Rates Up to 3Gbps W/ eSATA • Transfer Rates Up to 480Mbps W/ USB 2.
3. System Requirements / Parts Layout : Intel Pentium II 350 MHz-compatible Mac G3 processor & greater Microsoft Windows 2000/XP/ Vista Mac OS 9.2 & greater 1. USB port, eSATA port, FireWire 400 1. USB port, eSATA port, FireWire 400 (1394a) port (1394a) port 2. For USB 2.0 speeds, the system must 2. For USB 2.0 speeds, the system must support USB 2.0 specifications support USB 2.0 specifications 3. For FireWire speeds, the system must 3.
4. Installation : All in 1 Multifunction Internal Card Reader (5-1) Please remove the side panels of the case to gain access to the chassis. Once inside, remove the 5.25" front panel where you wish to place the card reader. ( Figure 5-A ) ( Figure 5-A ) (5-2) Insert the UGT-955-BK into the 5.25" bay as shown in the figure. ( Figure 5-B ) ( Figure 5-B ) (5-3) Tighten the screws of both sides. ( Figure 5-C ) ( Figure 5-C ) (5-4) Plug two SATA cables(Red) into the SATA ports on the motherboard.
Installation : (5-5) Plug the two USB cables from the device to the USB ports on the motherboard (Please consult the user's manual from the motherboard for the location of the USB ports) (Figure5-E) (USB Cable) ( Figure 5-E ) (5-6) Plug one 1394 cable to the 1394 port on the motherboard.(Please consult the user's manual from the motherboard for the location of the port) ( Figure 5-F) (1394 Cable) ( Figure 5-F ) (5-7) Lastly, put the side panels back on the case and secure with the screws.
5. FAQ / Warranty : 1. Q: Why is the power indicator not A: Please check the connection from the USB cable. illuminating? 2. Q: Why is the eSATA port not working? A: (1)Please check the connection of the SATA cable to your motherboard. (2)Some motherboards cannot support hotswapping using SATA. Please confirm with your motherboard manufacturer or your PC supplier for compatibility. WARNING : The All in 1 Multifunction Internal Card Reader comes with a 1 year limited warranty (90 day parts) .
6. / Contact : Contact Vantec Thermal Technologies 43951 Boscell Rd. Fremont, CA 94538 tel: 510-668-0368 fax: 510-668-0367 website: www.vantecusa.com Copyright © 2009 Vantec Thermal Technologies. All Right Reserved. All Registered Trademarks Belong To Their Respective Companies.
