PARTS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 21 of this manual.
VFB(F, L)32WS VFB(F, L)36WS FB(F, L)36RS FB(F, L)36RH VFB(F, L)42WS FB(F, L)42RS
FB(F, L)42RH
FBF36WS-LS
KEY
NO. PART NO. DESCRIPTION QTY.
1 108434-01 Left Refractory White Stack • 1
125280-01 Left Refractory White Stack • • 1
125290-01 Left Refractory White Stack • 1
125280-02 Left Refractory Red Stack • 1
125290-02 Left Refractory Red Stack • 1
125285-02 Left Refractory Red Herringbone • 1
125295-02 Left Refractory Red Herringbone • 1
2 108432-01 Right Refractory White Stack • 1
125281-01 Right Refractory White Stack • • 1
125291-01 Right Refractory White Stack • 1
125281-02 Right Refractory Red Stack • 1
125291-02 Right Refractory Red Stack • 1
125286-02 Right Refractory Red Herringbone • 1
125296-02 Right Refractory Red Herringbone • 1
3 108430-01 Rear Refractory White Stack • 1
125282-01 Rear Refractory White Stack • • 1
125292-01 Rear Refractory White Stack • 1
125282-02 Rear Refractory Red Stack • 1
125292-02 Rear Refractory Red Stack • 1
125287-02 Rear Refractory Red Herringbone • 1
125297-02 Rear Refractory Red Herringbone • 1
4 108426-01 Bottom Rear Refractory White Stack • 1
125283-01 Bottom Rear Refractory White Stack • • 1
125293-01 Bottom Rear Refractory White Stack • 1
125283-02 Bottom Rear Refractory Red Stack • 1
125293-02 Bottom Rear Refractory Red Stack • 1
125288-02 Bottom Rear Refractory Red Herringbone • 1
125298-02 Bottom Rear Refractory Red Herringbone • 1
5 108428-01 Bottom Front Refractory White Stack • 1
125284-01 Bottom Front Refractory White Stack • • 1
125294-01 Bottom Front Refractory White Stack • 1
125284-02 Bottom Front Refractory Red Stack • 1
125294-02 Bottom Front Refractory Red Stack • 1
125289-02 Bottom Front Refractory Red Herringbone • 1
125299-02 Bottom Front Refractory Red Herringbone • 1
6 116531-01 Retainer, Refractory • • • • • • • • 2
