3-8 Installation and Replacement
Installing The Vanguard 3400 Series
Rear Panel Ports There are up to twelve physical ports (8 voice, 2 LAN, 1 Serial, and 1 CTP) on the
Vanguard 3400 Series rear panel. Some physical port numbers may vary from model
to model.
Port 1
Port 1 of the 3410 is a RS232 Serial Interface. Port 1 of the 3460 is a Universal
(V.24/RS232, V.35/V.36, or V.11/X.21) Serial Interface..
.
The table below provides a description with part numbers of the Cable Adapter and
special cables (see
“Cable Adapters and Special Cables” section on page 3-9). The
paragraphs that follow provide more detailed information and pinouts.
3410 Motherboard Port 1
Cabling
Interface Type
DCE-DTE Crossover Cable Cable
Motherboard Port 1
V. 2 4 / R S 2 3 2 D C E N/A 80113 15' DB25M-DB25F
V. 2 4 / R S 2 3 2 D T E 80110 3' DB25M-DB25M
or 80109 15' DB25M-DB25M
N/A
3460 Motherboard Port 1 and 2-Port Serial Data Card Interface
Cabling
Interface Type
Y-Cable
(one per
2-PSDC)
Cable Adapter
(one per port)
DCE-DTE crossover
Cable (one per port)
Adapter Cable
(one per port)
Motherboard Port 1
V. 2 4 / R S 2 3 2 D C E N/A N/A N/A 80113
15' DB25M-DB25F
V. 2 4 / R S 2 3 2 D T E N/A N/A 80110
3' DB25M-DB25M
or 80109
15' DB25M-DB25M
N/A
V.35 or V.36 DCE N/A 1152-10021
DB25M-DB25F
N/A 92104
7' DB25M-M34F
V.35 or V.36 DTE N/A 1152-10021
DB25M-DB25F
51177
1' DB25M-DB25F
91917
7' DB25M-M34M
V. 11 / X . 2 1 D C E N/A 1152-10022
DB25M-DB25F
N/A 92089
7' DB25M-DB15F
V. 11 / X . 2 1 D T E N/A 1152-10022
DB25M-DB25F
51176
1' DB25M-DB25F
91918
7' DB25M-DB15M
2-Port Serial Data Card
V. 2 4 / R S 2 3 2 D C E 62026-01 DB50M-
two DB25Fs
N/A N/A 80113
15' DB25M-DB25F
