2-6 Hardware Description
Vanguard Networks Daughtercards
Vanguard Networks Daughtercards
Supported
Daughtercards
The table below identifies the daughtercards supported by each 3400 series model, as
well as any daughtercard slot restrictions that may apply.
Note
If a table entry contains the value "Yes", the daughtercard type will be supported
in the DC Site for that platform.
If a table entry contains the entry " --- ", the daughtercard type will not be
supported in that DC Site of that platform
Vanguard 3410 Daughtercard Matrix
Description Product
Code
Assembly
Number
3410 3460
DC
Site
DC
Site 1
DC
Site 2
2P-SDC (2-Port Serial) 1130-10004 --- Yes ---
56K DSU 68472 Yes Yes Ye s
Dual E&M 65729 --- Ye s Yes
Dual FXS 68372 --- --- ---
FT1 - 120 Ohm 49666 Yes Ye s Yes
FE1 - 120 Ohm 49669 Yes Ye s Yes
FE1 - 75 Ohm 49716 Yes Yes Ye s
FXS/FXO 80019 --- --- ---
G.SHDSL 1152-10009 --- --- ---
Quad FXO 1152-10035 --- Ye s Yes
Quad FXS 1152-10034 --- Yes Yes
ISDN BRI S/T 68525 --- --- ---
ISDN BRI S/T 1152-10005 --- --- ---
ISDN BRI-U 68434 --- --- ---
V.11 DCE (Serial) 49649 --- --- ---
V. 2 4 D C E ( S e r i a l ) 49646 --- --- ---
V. 3 5 D C E ( S e r i a l ) 49647 --- --- ---
V. 3 6 D C E ( S e r i a l ) 49648 --- --- ---
V.11 DTE (Serial) 49661 --- --- ---
V.24 DTE (Serial) 49658 --- --- ---
V.35 DTE (Serial) 49659 --- --- ---
V.36 DTE (Serial) 49660 --- --- ---
V. 9 0 ( M o d e m ) 1152-10003 --- Yes Yes
