Datasheet

Contents: Camera, CD, QIG, drill template, screws
* Similar to illustration
Value 1080p Fix Dome HD-TVI Camera
VTDOF2-1
Features:
• Up to 2 megapixel (1920 × 1080) resolution
• HD-TVI video transmission over Coax cable
• Angle of view:: 105.8°(2.8mm lens)
• Built-in IR Illuminators up to 30 meters
• Weather-proof IP66 rated housing
• Impact Protection IK10
• OSD menu controlled via UTC
Specification: Dimension:
Model
Parameter
21.99.1642 - VTDOF2-1
1080p CMOS HD-TVI Infrared Dome Camera
Camera
Image Sensor
Progressive Scan CMOS
Signal System
PAL / NTSC
Min. Illumination
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
Shutter Speed
1/25 s to 1/100,000 s
Lens
2.8mm@ F2.0
Angle of view: 105.8°
Lens Mount
M12
Day &Night
IR cut filter with auto switch
Digital Noise Reduction
3D DNR
Effective Pixels
1930 x 1088
Frame Rate
50Hz: 1080p @ 25 fps
60Hz: 1080p @ 30 fps
Backlight compensation
Yes
Interface
HD Video Output
1 HD-TVI Output
OSD Menu
Language
English/ Chinese
Communication
Over coax cable
BLC
Support
D / N Mode
Color/ BW/ EXT
White Balance
Auto/ Manual
General
Operating Conditions
-40 °C – 60 °C (-40 °F – 140 °F)
Humidity 95% or less (non-condensing)
Power Supply
DC12V ± 10%
Power Consumption
Max. 3W
Ingress Protection level
IP66
Impact protection
IEC60068-2-75Eh, 50J; EN50102, up to IK10
IR Range
Up to 20 Meter
Dimensions
Φ70×149.5mm (Φ2.76”×5.89”)
Weight
290g (0.64lbs)
Box content: Camera, CD, QIG, Alignment sticker, screws
Specicaon: Dimensions:
Similar to illustraon!
VALUE1080pFixDomeHD-TVIKamera
VTDOF2-1
Features:
• Upto2megapixel(1920×1080)resoluon
• HD-TVIvideotransmissionoverCoaxcable
• Angleofview::105.8°(2.8mmlens)
• Built-inIRIlluminatorsupto30meters
• Weather-proofIP66ratedhousing
• ImpactProteconIK10
• OSDmenucontrolledviaUTC
