User guide

1. Parts and Funcons

2. Door Staon Mounng

35mm

145 cm

1. Dig a hole in 75mm X 75mm X 35mm in the wall. Insert the mounting bracket and x with screws.

2. Wire up the cables, and test the system.

3. Hang the door/bell camera body on top of the mounting box, then tighten the screws rmly on the

bottom.

1. Microphone

2. Camera

3. Night-View LED

4. Call Button

5. Speaker

6. Angle Adjust

7. Monitor Port

8. Unlock Port LB
