SL-2M Lamp
Invisible inks or
altered documents
fluoresce when
exposed to the UV.
Signature and fraud detection UV lamps use longwave UV to
check the authenticity of signatures, documents, tickets, passports,
currency and credit cards.
Easy to operate
Easy to detect forged documents and currency
Safe to use
Ordering Information
SL-2M Fraud Detection
UV Lamp, 4-watt, 365nm
95-0164-01 (115V)
95-0164-02 (230V)
UVL-4 UV Lamp, 4-watt, 365nm 95-0125-01 (4-AA not included)
Replacement Tube, 4-watt, BLB 34-0010-01
Dimensions:
SL-2M: 6.5W x 5.75D x 4.5H in. (165 x 145 x 114 mm)
UVL-4: 6.25L x 1W x 2H in. (159 x 25 x 51mm)
Mineralight R-52G Grid Lamp provides a powerful, uniform
source of high-intensity 254nm shortwave UV.
Dimensions:
7.8H x 16L x 7.8W in. (198 x 406 x 198mm); Primary cord:
8 ft., secondary cord 3 ft.); Weight: 9.5 lb (4.3 kg)
Ordering Information
R-52G Grid Lamp
254nm UV
94-0012-05 (115V)
94-0012-06 (230V)
R-52G Grid Replacement 77-0002-02
For small scale mineral displays and laboratory applications
including bacteria destruction, sterilization and photochemistry
Removable filter assembly converts the lamp from fluorescent
analysis to sterilizing uses
R-52G provides high intensity 254nm UV. Lamp
mounts securely to the base for hands free use.
Eye and face protection is essential for anyone working with ultraviolet
sources which can cause burning to unprotected eyes and skin. Eyewear
blocks wavelengths from 200 - 400nm.
Spectacles are made of impact resistant polycarbonate. Top and
side-shield design provides UV protection for the eyes. Orange
spectacles block blue light that can cause haze.
Goggles are constructed of specially-formulated plastic for optimum
viewing contrast and lessened eye fatigue. Goggles feature a
lightweight design and flexible rubber trim. Air vents allow air flow
while blocking ultraviolet transmission.
Faceshield covers the face and neck area.
Dimensions:
Spectacles: 2H x 6W in. (51 x 152mm)
Goggles: 3H x 6W in. (76 x 152mm)
Faceshield: 17dia x 8.25H in. (432 x 210mm)
Eyewear protects the eyes from harmful UV.
Ordering Information
UVC-303 Spectacles
UVC-310 Spectacles, orange
98-0002-01
38-0240-01
Goggles UVC-503
Replacement Goggle Lens
98-0002-02
98-0002-03
Faceshield UVC-803
Replacement Shield
98-0002-04
38-0151-01
Signature UV Lamps
Mineralight
®
UV Lamps
UV Blocking Eyewear
Goggles and Faceshield comply with ANSI-Z87.1 1986
specifications for eye and face protection devices.
34 7
Basic and Advanced Imaging Systems Ultraviolet Lamps
GelDoc-It Imaging Systems
GelDoc-It
e
Imaging Systems provide a plug-and-play configuration with a compact, easy-to-
operate design. VisionWorks
®
LS Software (see page 39 for details) features efficient image
capture, quantitative 1D analysis
and gel documentation capabilities.
Monochrome FluorCam 220 CCD camera
Compact design and small size
for limited laboratory space
Zoom lens is easily accessible for
adjustment of aperture, zoom and focus
Side access doors for repositioning
gels while viewing gel fluorescence
through the window
Epi white light for focusing and
illumination of samples
Ethidium bromide filter is placed
in the slide-out filter tray; allows
easy exchange of filter
Integrated UV Transilluminator
Unique viewer window allows UV-safe
viewing of gels without opening the door
Safety switch turns UV off when
the door is open
Camera Specifications
Model:
CCD Type:
Resolution:
Pixel Resolution:
Grayscale:
Lens:
FluorCam 220
Monochrome 12-bit
1.3 megapixels, extendable
to 5.0 MP
1280 x 1024
0 - 65,535
8-48 mm zoom
GelDoc-It
e
includes: CCD monochrome camera/lens, darkroom, epi white light, Ethidium
bromide filter, choice of transilluminator, VisionWorksLS capture/analysis software (loads on
user’s computer; compatible with Windows 7 or higher).
* Applications may require light
plates. See page 27 for plates.
Dimensions:
30.7H x 14.2W x 13.3D in. (780 x 361 x 338mm)
GelDoc-It
e
Applications*
Ultraviolet Lamps
UV Blocking Eyewear
Advanced Imaging Systems
GelMax
®
Imager
The compact GelMax Imager captures brilliant publication quality
images of precast and mini gels up to 11.5 x 16cm. Illuminate stained
gels with interchangeable transillumination sources: midrange (built-in),
white, blue and longwave UV. Analyze results using simple workflow-
focused software which loads on user’s PC. *Applications may require
additional light plates; see ordering information below.
GelMax Imager Ordering Information
GelMax Imager 97-0672-01 (115V) | 97-0672-02 (230V)
Camera Color, high resolution**
Darkroom
Compact size, epi white light built-in, 5-position
filter wheel (EtBr filter included)
Transillumination
Lighting
302nm UV (filter size 11.5 x 16cm) built-in
10-minute shutoff timer
Light Plates,
(optional)
11.5 x 16cm
Longwave 365nm UV (38-0381-01)
Visi-Blue 460/470nm (38-0381-02)
White light (38-0381-03)
Software
Doc-It
®
LS capture and analysis (Win XP or higher)
GelMax Imager is designed with interchangeable light
plates for imaging of precast and mini gels.
Filter tray - 5
positions (with
Etbr filter)
302nm UV -
add light plates
for viewing
11.5 x 16 cm
precast gels
Lighting
controls
GelMax Applications*
Basic Imaging Systems
®
e
GelMax includes: Color camera, darkroom, ethidium bromide filter, 302nm
transilluminator, black tray, Doc-It capture/analysis software (loads on user’s
PC). **For current camera specifications, go to UVP.com or contact UVP.
Dimensions: 15.5H x 12.8W x 13D in. (394 x 325 x 330mm)
Color camera
