Specifications

Portable & Rechargeable UV Lamps
Mini UV Lamps
UVP ... [phone] | [phone] | [phone] | UVP.com
Excellent lamps for office or field inspection
Lamps are lightweight and can fit into a pocket
A nylon strap is attached for easy handling
Dimensions:
UVG-4, UVSL-14P 6.25L x 1W x 2.6H in. (159 x 25 x 66mm)
UVL-4 6.25L x 1W x 2H in. (159 x 25 x 51mm)
UVL-4F 6.5L x 2W x 1H in. (165 x 51 x 25mm)
Ordering Information
UVG-4 4-watt, 254nm
Replacement Tube
95-0158-04 (4AA)
34-0003-01
UVL-4 4-watt, 365nm BLB
Replacement Tube
95-0125-05 (4AA)
34-0010-01
UVSL-14P Multiband split-tube
4-watt, 254nm/365nm
Replacement Tube
95-0188-02 (4AA)
34-0004-01
UVL-4F 4-watt, 365nm BLB/Flashlight
Replacement Tube
95-0305-03 (4AA)
34-0010-01
Mini UV Lamps
UVG-4, UVSL-14P,
UVL-4.
UVL-4F Mini UV Lamp includes a
longwave UV tube and a flashlight.
Portable UV lamps have 6 watts and are operated by
two 6-volt lantern batteries.
The distinctive wrap around
handle comfortably balances
the lamp in your hand
A built-in flashlight is included
Optional rechargeable 6V
batteries and charger are
available
Portable UV Lamps are
lightweight for field use.
Portable Lamp - Ordering Information
ML-49 6-watt, 365nm BLB
Replacement Tube
95-0011-01 (12V)
34-0016-01
UVG-47 6-watt, 254nm
Replacement Tube
95-0009-02 (12V)
34-0013-01
UVGL-48 split-tube
6-watt, 254nm/365nm
Replacement Tube
95-0010-02 (12V)
34-0015-01
Bulb, White 34-0014-01
Battery, 6V 45-0005-01
Battery, rechargeable 6V (115V)
Charger (115V)
45-0005-02
58-0136-01
Portable UV Lamp Dimensions:
9.5L x 2.8W x 9.4H in. (241 x 71 x 239mm)
Weight: 4 lb (1.8 kg)
Rechargeable UV lamps (6-watt) feature a lightweight design
and come in three dual-tube models.
Lamps are equipped with an
internal gel based, lead-acid
battery which can be charged
from a standard wall outlet
UVSL-26P (shown) can operate
with both longwave and short-
wave at the same time
Optional 12V adapter powers
the lamp from a car cigarette
lighter
Use with the C-10P Cabinet
(see page 13 for details)
Rechargeable UV
Lamps with built-in
rechargeable battery.
Rechargeable Lamp Dimensions:
5.5L x 3.0W x 9.8H in. (140 x 76 x
249mm); Weight: 4 lb (1.8 kg)
Rechargeable Lamps - Ordering Information
UVL-26P
6-watt, 365nm
Replacement Tube, 365nm BLB
95-0186-01 (115V)
95-0186-02 (230V)
34-0016-01
UVS-26P
6-watt, 254nm
Replacement Tube, 254nm
95-0187-01 (115V)
95-0187-02 (230V)
34-0013-01
UVSL-26P 6-watt
254nm/365nm
Replacement Tube, 365nm
Replacement Tube, 254nm
95-0181-01 (115V)
95-0181-02 (230V)
34-0034-01
34-0013-01
Adapter, 12V 58-0127-02
6
35
Mini UV Lamps are 4-watt models with
longwave (365nm), shortwave (254nm)
ultraviolet or multiband split-tube shortwave
and longwave in one unit. Lamps operate on
four AA batteries (not included).
Ultraviolet Lamps
Advanced Imaging Systems
ChemiDoc-It
TS2
810: Class-leading image resolution and cooled CCD
(MegaCam 810) with 8.1 MP resolution. Enables shorter exposure times in
chemiluminescence, fluorescence and colorimetric applications.
ChemiDoc-It
TS2
510: Cooled CCD camera (BioChemi 510) with 2.1 MP
delivers affordable, high sensitivity for chemiluminescence, fluorescence
and colorimetric applications.
GelDoc-It
TS2
310 with a high resolution CCD camera (GelCam 310) with
2.0 MP resolution for fluorescence and colorimetric imaging applications.
Chemi Tray enables placement
of samples such as chemilumi-
nescent Western blots
(ChemiDoc-It
TS2
only)
Emission Filters are
placed in the easy access
five-position filter tray
An ethidium bromide filter
is standard; additional
filters are available
Large Touch Screen is integrated
into the system with a generous
15.6” for easy viewing and selection
of functions
TS2 Software features an
intuitive control panel for
simplifying the imaging workflow
CCD Camera and lens,
built into the cabinet, offer
high sensitivity for a variety
of imaging applications
Transilluminator is
placed on the easy access
roll-out tray
Choose from models with
single UV or multiple UV
wavelengths and filter
sizes from 21x26cm to
25x26cm
Epi White Lights are built
into the cabinet for lighting
and focusing purposes
System Selection
ChemiDoc-It
TS2
Applications*
USB Ports are located on the
side of the cabinet for saving
images; or transfer images via
network connectivity
Side Port provides access for
the optional BioLite source
Light-Tight Cabinet is
ideal for chemiluminescent
imaging applications
ChemiDoc-It and GelDoc-It Imaging Systems
GelDoc-It
TS2
Applications*
* Applications listed may require additional accessories.
The ChemiDoc-It
TS2
and GelDoc-It
TS2
Imaging Systems feature a large integrated
touch screen with easy touch buttons for
image preview, capture and save functions.
System Specifications:
Monitor: 15.6” touch screen
Computer: Integrated into system
Software: TS2 image capture software
Camera/Lens: See specifications p. 39
Save Options: USB stick or transfer images
via network (wireless or wired)
Darkroom: Light tight
Chemi tray (ChemiDoc-It only)
Epi Light: White Light
Transillumination: Single or Multiple UV
Filter sizes: 21x26 or 25x26cm
Emission Filters: EtBr (580-630nm)
Five position filter wheel
Other filters available
Systems includes: Camera and lens, darkroom with
built-in computer touch screen, EtBr filter, epi white
light, choice of transilluminator, USB flash drive,
keyboard and mouse. System configurations may
vary by country. Contact UVP for system details.
Advanced Imaging Systems
Ultraviolet Lamps
TS2 TS2
®®
Unique viewer
window allows
UV-safe viewing
of gels without
opening the door
Dimensions (WDH): 17.5 x 14.5 x 33.5 in.
(44.4 x 36.8 x 85.1cm)
