Specifications

Dimensions J-129: 9.75H x 13L in. (248 x 330mm)
UVP ... [phone] | [phone] | [phone] | UVP.com
Ultraviolet Lamps
Compact UV Lamps (4-watts) feature an
on/off switch conveniently located on the back
of the lamp.
J-124 Stand for use with Compact
UV Lamps.
Dimensions Compact Lamps:
7.8L x 2.8W x 2.1H in. (198 x 71 x 53mm)
Weight: 1 lb (0.45kg)
Dimensions J-124 Stand:
6.5H x 7.5W x 4.8D in. (165 x 190 x 122mm)
Handheld UV Lamps (6-watts) include shortwave (254nm), longwave
(365nm) UV or the combination shortwave/longwave in one lamp.
Comfortable, ergonomically designed handle for easy handling
On/off switch is located on the back of the lamp
Handheld Lamps - Ordering Information
UVG-54
6-watt, 254nm UV
Replacement Tube
95-0004-09 (115V)
95-0004-10 (230V)
34-0013-01
UVGL-55 (split-tube)
6-watt, 365nm/254nm UV
Replacement Tube
95-0005-05 (115V)
95-0005-06 (230V)
34-0015-01
UVL-56
6-watt, 365nm UV
Replacement Tube
95-0006-02 (115V)
95-0006-03 (230V)
34-0034-01
UVM-57
6-watt, 302nm UV
Replacement Tube
95-0104-01 (115V)
95-0104-02 (230V)
34-0044-01
UVGL-58
6-watt, 365nm/254nm UV
Replacement Tube 365nm UV
Replacement Tube 254nm UV
95-0007-05 (115V)
95-0007-06 (230V)
34-0034-01
34-0013-01
Handheld UV
Lamps are
lightweight 6-
watt models.
Shown with
optional J-129
Lamp Stand
for hands-free
lamp use.
Compact Lamps - Ordering Information
UVG-11
4-watt, 254nm UV
Replacement Tube
95-0016-14 (115V)
95-0016-15 (230V)
34-0003-01
UVGL-15 (split-tube)
4-watt, 365nm/254nm UV
Replacement Tube
95-0017-09 (115V)
95-0017-10 (230V)
34-0004-01
UVL-21
4-watt, 365nm UV
Replacement Tube
95-0018-02 (115V)
95-0018-03 (230V)
34-0005-01
UVGL-25
4-watt, 365nm/254nm UV
Replacement Tube 365nm UV
Replacement Tube 254nm UV
95-0021-12 (115V)
95-0021-10 (230V)
34-0005-01
34-0003-01
UVL-23
4-watt, 365nm BLB UV
Replacement Tube
95-0019-01 (115V)
95-0019-03 (230V)
34-0010-01
UVL-23R
4-watt, 365nm BL UV
Replacement Tube
95-0019-14 (12V)
34-0005-01
J-124 Lamp Stand 98-0020-03
Handheld UV Lamps
38
3
Combination wavelength version comes with a snap-on selector
plate for switching between wavelengths
Lightweight, easy-to-handle lamp design
Comes in 12V style (for cigarette lighter operation)
Compact UV Lamps (4-watts) feature models with longwave (365nm),
shortwave (254nm) or multiple UV.
Ultraviolet Lamps
J-129 Lamp Stand 98-0016-03
Compact and Handheld UV Lamps can be used with
viewing cabinets for illumination of samples in a darkroom
environment. See page 13 for details.
Dimensions Handheld Lamp: 14.9L x 3.2W x 2.5H in.
(378 x 81 x 64mm) Weight: 2 lb (0.91kg)
iBox Explorer Imaging Microscope
iBox Scientia Imaging System
iBox Explorer
TM
Imaging Microscope is designed for macro
to micro (0.17X to 16.5X) detection of fluorescent markers from
whole organ to individual cell. Researchers can visualize
and capture visible to NIR multispectral fluorescently
labeled cells in vivo.
iBox Explorer
Applications
iBox Scientia
Applications
The iBox Scientia Imaging System allows non-invasive whole animal mouse imaging
for pre-clinical research including tumor studies, metastases and immunology.
Capture images with the high
sensitivity CCD camera and optics,
ideal for in vivo imaging applications
View whole animal down to single
cell via motorized optics
BioLite
TM
Xe MultiSpectral
Light Source with xenon
light for excitation of a wide
range of fluorescent stains;
includes GFP/RFP filter set
Acquire images and produce
quantitative analysis results with
VisionWorks
®
LS Software
Maintain uniform animal temperature
for up to two mice on the slide-out
warming plate built into the system
Seamlessly navigate through
the parcentered and parfocal
magnification levels and field
of view (FOV):
0.17x (90x90mm FOV) to
16.5x (0.9x0.9mm FOV)
Adjust the location of the motorized X, Y, Z platform via the
external joystick; fine tune and bookmark stage positions
using the software interface
Capture superior images with CCD
camera and optics for optimized
visible to NIR imaging
Select the desired emission filter by
software automation
Connect the BioLite
TM
multispectral
fiber optic cable through the
port for directed visible to NIR
epi illumination
BioLite
TM
MultiSpectral
Light Source (Xenon or
Halogen) for excitation of a
wide range of fluorescent
stains; includes GFP/RFP
filter set
Attach an external anesthesia unit
(optional) via an access port in
the darkroom
Generate accurate analysis data with
VisionWorks
®
LS Software
Keep mice at optimum temperature
with the warming plate placed on
the easy access roll-out tray
Advanced Imaging Systems
Advanced Imaging Systems
Ultraviolet Lamps
Advanced Imaging Systems
For detailed system specifications, application notes, videos and other
information, go to uvp.com or scan the QR code for links to imaging systems.
®
®
