UVP ... [phone] | [phone] | [phone] | UVP.com
Table of Contents / About UVP
Ultraviolet Lamps: Hand & Specialty
Compact & Handheld . . . . . . . . . . . . . . . . . . . . 3
3UV and EL Series . . . . . . . . . . . . . . . . . . . . . 4
Mini, Portable & Rechargeable . . . . . . . . . . . . 6
SL-2M Signature Verification . . . . . . . . . . . . . 7
R-52G Mineralight Grid . . . . . . . . . . . . . . . . . . 7
UV Blocking Eyewear . . . . . . . . . . . . . . . . . . . . . . 7
Ultraviolet Lamps: High Intensity & Display
B-100 High Intensity Series . . . . . . . . . . . . . . 8
BL-15 Inspection Lamp . . . . . . . . . . . . . . . . . . 9
225D Bench Series . . . . . . . . . . . . . . . . . . . . 10
UVGD-68 Grid Mineralight Lamp . . . . . . . . . 10
XX Series Bench Lamps . . . . . . . . . . . . . . . . 10
Blak-Ray Fluorescent Inks . . . . . . . . . . . . . . . . . 11
Chromato-Vue Cabinets . . . . . . . . . . . . . . . . . . . 12
Pen-Ray Light Sources
Mercury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Grids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Rare Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power Supplies . . . . . . . . . . . . . . . . . . . . . . . 15
Zinc and Cadmium . . . . . . . . . . . . . . . . . . . . 16
Field Packs . . . . . . . . . . . . . . . . . . . . . . . . . . 16
PCQ PhotoChemical Quartz . . . . . . . . . . . . . 16
Stable Ozone Generators . . . . . . . . . . . . . . . 16
UV Intensity Meters
UVX Radiometer and J-Series . . . . . . . . . . . 17
PCR Systems
UV PCR Cabinets and Workstations . . . . . . . 18
UV3 HEPA PCR Cabinets and Workstations . 19
Hybridization Ovens
HB-1000 Hybridizer . . . . . . . . . . . . . . . . . . . . 20
HL-2000 HybriLinker (Oven/UV Crosslinker) . 20
HM-4000 Multidizer . . . . . . . . . . . . . . . . . . . . 21
HB-500 Minidizer . . . . . . . . . . . . . . . . . . . . . . 21
Crosslinkers and Translinker . . . . . . . . . . . . . . 22
Transilluminators
FirstLight UV Illuminator . . . . . . . . . . . . . . . . 23
Benchtop . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
High Performance . . . . . . . . . . . . . . . . . . . . . 25
Visi-Blue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
UV/White Light . . . . . . . . . . . . . . . . . . . . . . . . 26
White Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Converter Light Plates & Gel Tools . . . . . . . . . . 27
UV Incubator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
BioImaging Systems Overview . . . . . . . . . . . . . . .28
BioImaging System Applications . . . . . . . . . . . 28
Basic Imaging Systems
ColonyDoc-It . . . . . . . . . . . . . . . . . . . . . . . . . 29
ChromaDoc-It and MultiDoc-It . . . . . . . . . . . . 30
DigiDoc-It . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
1D Analysis Software . . . . . . . . . . . . . . . . . . . 31
BioDoc-It . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
PhotoDoc-It . . . . . . . . . . . . . . . . . . . . . . . . . . 33
GelMax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Advanced Imaging Systems
GelDoc-It
e
. . . . . . . . . . . . . . . . . . . . . . . . . . . 34
GelDoc-It
TS2
& ChemiDoc-It
TS2
. . . . . . . . . . . 35
GelDoc-It
2
& ChemiDoc-It
2
. . . . . . . . . . . . . . 36
BioSpectrum . . . . . . . . . . . . . . . . . . . . . . . . . 37
iBox Explorer & iBox Scientia . . . . . . . . . . . . 38
Advanced Imaging System Cameras . . . . . . 39
VisionWorksLS Software . . . . . . . . . . . . . . . . 39
Thermal Printer . . . . . . . . . . . . . . . . . . . . . . . . . . 39
UV Applications . . . . . . . . . . . . . . . . . . . Back Cover
Where to Order . . . . . . . . . . . . . . . . . . . Back Cover
Analytik Jena Products . . . . . . . . . . . . Back Cover
392
Contents / About UVP
Camera/Lens Specifications
Specifications MegaCam 810 OptiChemi 610** BioChemi 510 GelCam 310
CCD/File Bit Depth (A/D) 16 bit / 16 bit 16 bit / 16 bit 16 bit / 16 bit 12 bit / 16 bit
Grayscale Range 65,536 65,536 65,536 65,536
Pixel Resolution 3296 x 2472 2184 x 1472 2336 x 1751 1600 x 1200
Megapixels (MP) 8.1, extendable to 16.2* 3.2, extendable to 9.6*;
2.1 (with zoom lens), extendable
to 7.4*; 4.1 (with fixed lens),
extendable to 12 MP**
2.0, extendable to 6.0*
Cooling Type (Peltier) -35
O
C from ambient -50
O
C from ambient -35
O
C from ambient None
Binning Modes 1x1 thru 8x8 1x1 thru 10x10 1x1 thru 8x8 None
Quantum Efficiency
Peak & Chemi 425nm
50% & 44% 86% & 53% 50% & 32% ---
Lens Options (Motorized or
manual; call UVP for details)
50mm f/1.2, 30mm f/1.4,
25mm f/0.95**
50mm f/1.2, 30mm f/1.4,
25mm f/0.95
12.5-75mm f/1.2,
25mm f/0.95**
12.5-75mm f/1.2
* Extendable megapixels function does not apply to ChemiDoc-It
TS2
or GelDoc-It
TS2
Systems. ** Not for ChemiDoc-It
TS2
or GelDoc-It
TS2
.
VisionWorksLS is a powerful software package designed with
comprehensive tools to facilitate the capture and analysis of
publication quality images. The software is used with UVP’s
Advanced Imaging Systems. Software capabilities include:
Image acquisition controls
Image enhancement functions
1D quantitation, area density analysis and colony counting
User defined master templates
Report generation and export of data to Excel
Support for 21 CFR Part 11 compliance
Area Density Use the
Area Density function
to determine intensity
information. Generate
lane profile graphs,
dendrogram analysis
and calculation of
concentration curves
The software enables easy selection of a variety of
functions to achieve superior captured images.
Exposure and integration controls include:
Integration: On-chip integration for single image
capture. Sequential integration captures multiple
pictures taken at increasing exposure times.
Dynamic integration captures images at set
intervals.
AutoExpose enables the perfect image exposure
of gels and blots captured automatically below the
saturation level of each pixel in the image.
Pre-Set and User-Defined Master Templates are
great time savers and allow users to set and save
darkroom and camera
settings for quick, easy
capture of samples.
Use of templates aids
in simplifying the image
capture process,
especially for repeat
experiments.
Advanced Imaging Systems
Advanced Imaging Systems
Document gel and blot images with a 256 grayscale thermal printer.
Compact printer easily connects to any of UVP’s imaging systems
(except the PhotoDoc-It).
Low cost prints in seconds
High resolution, 3x4” archive-
quality thermal prints
Thermal Printer
Thermal Printer
Ordering Information
Digital Thermal Printer Mitsubishi
89-0069-06 (115V)
89-0069-07 (230V)
Digital Thermal Printer
Sony (for Europe)
89-0357-01 (230V)
Thermal Paper, Mitsubishi
High density, 4 rolls (800 prints)
Thermal Paper, Sony super glossy
UPP110HG 5 rolls (1000 prints)
Thermal Paper, Sony glossy
UPP110HA 5 Rolls (1000 prints)
89-0038-01
89-0174-01
89-0031-01
Printer Dimensions:
6W X 9.5D X 3.3H in. (154 X 240 X 84mm)
Thank you for your interest in UVP’s products. We look forward to
assisting you with product information plus technical and sales
assistance. We appreciate the opportunity to be of support to you.
This catalog covers UVP’s general line including ultraviolet and
laboratory products, light sources and Basic Imaging Systems.
Highlights of UVP’s Advanced Imaging Systems are provided.
Additional information is available on our website at UVP.com
including further product details, application notes, technical support
information and new product releases.
Since 1932, UVP has created and designed ultraviolet lamps and
products for science, industry and education. Today, UVP continues
its research and development of laboratory equipment such as an
extensive array of gel documentation and imaging systems, ultraviolet
products, hybridization ovens and UV sterilization equipment.
Applications for UVP's instruments includes chemiluminescence,
electrophoresis, fluorescence, bioluminescence, colorimetric,
sterilization and more. See the difference in your results with UVP's
equipment. Easily visualize, identify, document and analyze with
assurance that you are using quality, reliable equipment from UVP.
In addition to over 100 employees in our Upland facility, UVP has a
worldwide network of sales, service and support representatives to
assist with your requirements. Our innovative engineering and state of
the art manufacturing techniques and equipment make UVP products
the first choice of leading organizations around the world. Integrated
manufacturing processes allow quick turnaround of production. UVP’s
capabilities combine computer-aided product design engineering,
cost-effective sheet metal and paint production, focused work-cell
assembly and inspection and quality control assurance for complete
customer satisfaction.
UVP is now part of Analytik Jena which is located in Jena Germany.
Analytik Jena offers an extensive Life Science product line which
complements UVP’s products. Many Analytik Jena Life Science
products are available through UVP in the Americas. Contact UVP’s
Upland office for product information.
UVP’s headquarters and manufacturing facility is located in Upland,
California. The European operations, Ultra-Violet Products Ltd., is
located in Cambridge, England.
UVP Trademarks: Doc-It, BioSpectrum, iBox, VisionWorks, Blak-Ray,
Chromato-Vue, Mineralight, FirstLight and Pen-Ray are registered trademarks
of UVP, LLC. BioDoc-It, DigiDoc-it, MultiDoc-It, GelDoc-It, PhotoDoc-It,
ColonyDoc-It,ChromaDoc-It, ChemiDoc-It, Visi-Blue, 2UV, 3UV, Visi-Blue,
Translinker, HybriLinker, Minidizer, HybriLinker, Multidizer and Cool-Touch are
trademarks of UVP, LLC. All other trademarks are acknowledged as owned by
their respective owners.
UVP’s Upland
facility is
located in
Southern
California
About UVP
Contents
Advanced Imaging Systems Camera Specifications
VisionWorksLS Software
