Specifications

The mini Chromato-Vue
®
UV Viewing Cabinets are designed
with a metal base and plastic top. The C-15G cabinet includes
a UVGL-58 UV lamp. Lamps for other mini cabinets are
ordered separately.
C-15G Mini UV Cabinet
Combines the C-10
Cabinet with UVGL-58
multi-band lamp with
shortwave and longwave.
The bottom panel of the cabinet is removable
The lamp fits snugly on top of the cabinet
A contrast control filter absorbs UV energy and protects
the eyes
Soft rubber viewport provides a comfortable viewing area
with space for eyeglasses
Lightweight access curtain blocks out external light from
the cabinet interior
C-10P Mini UV Cabinet
accommodates the 6-watt
Rechargeable Lamps which
are excellent for field use
applications (see page 6 for
Rechargeable Lamps).
C-10E4 Mini UV Cabinet
Designed for use with the
4-watt EL Series Lamps
(see pages 4 - 5).
Ordering Information
C-10 Mini Cabinet for 4 and 6-watt PL
Series UV Lamps
95-0072-01
C-10P Mini Cabinet for 6-watt Portable
Rechargeable Lamps
95-0072-02
C-10E4 Mini Cabinet for 4-watt
EL Lamps
95-0072-08
C-10E6 Mini Cabinet for 6-watt
EL Lamps
95-0072-09
C-15G Mini Cabinet with
UVGL-58 UV Lamp
95-0072-06 (115V)
95-0072-07 (230V)
Mini Cabinet Dimensions:
Interior: 8.75L x 10W x 7H in.
(222 x 254 x 178mm)
Exterior: 9L x 10.5W x 12H in.
(229 x 267 x 305mm)
Ordering Information
C-65 Mid-Size UV Viewing
Cabinet
95-0257-01 (115V)
95-0257-02 (230V)
C-65 UV Cabinet is designed to accommodate one
or two of the EL Series 8-watt Lamps
The bottom panel of the cabinet is removable
Includes an interior overhead white light
Access curtain blocks ambient light
C-65 Chromato-Vue Cabinet accommodates one or two
EL Series 8-watt lamps ordered separately. Several lamps
are listed below. For additional lamps, see pages 4 - 5. Use of
two lamps illuminates the interior uniformly from two sides of
the cabinet.
Lamps are made with a durable, scratch-resistant metal
Lamps include a universal plug, which connects directly
to the C-65 Cabinet, plus a supplementary power cord
for use of the lamp separately from the cabinet
EL Series 8-watt lamps can be used with the C-65 cabinet or
removed for handheld use (see p. 4-5 for more EL Lamps).
Ordering Information - EL Lamps
UVL-28
365nm/365nm UV
95-0248-01 (115V)
95-0248-02 (230V)
UVS-28
254nm/254nm UV
95-0249-01 (115V)
95-0249-02 (230V)
UVLS-28 (2UV)
365nm/254nm UV
95-0201-01 (115V)
95-0201-02 (230V)
UVLMS-38 (3UV)
365nm/302nm/254nm UV
95-0252-01 (115V)
95-0252-02 (230V)
C-65 Dimensions:
Interior: 17L x 14W x 6H in. (533 x 330 x 400mm)
Exterior: 19.75L x 16.5W x 15.75H in. (602 x 419 x 400mm)
Mini UV Viewing Cabinets
Multifunctional UV Cabinet
13
UVP ... [phone] | [phone] | [phone] | UVP.com
28
BioImaging Systems
Chromato-Vue Viewing Cabinets
Chromato-Vue Viewing Cabinets
System/Spec
CCD
Camera
Epi Lighting Transilluminator Filter Filters Touch Software
White Blue UV White Blue UV Tray Spots Included Screen Capture Analysis
BioSpectrum Cooled* X X X X Opt X 5 3 X X
ChemiDoc-It Cooled X X X
ChemiDoc-It
TS2
Cooled X Opt Opt Opt X 5 1 15.6” X X
ChemiDoc-It
2
Cooled X Opt Opt Opt X 4 1 X X
GelDoc-It
TS2
Non-cooled X Opt Opt Opt X 5 1 15.6” X X
GelDoc-It
2
Non-cooled X Opt Opt Opt X 4 1 X X
GelDoc-It
3
Non-cooled X Opt Opt X 1 1 X X
Note: System configurations may vary by country. iBox Series Imaging Systems for in vivo imaging also available. See page 38 for details.
* BioSpectrum may be configured with a cooled or non-cooled monochrome CCD camera.
System/Spec
Camera
Type
Epi Lighting Transilluminator Filter Filters Touch Software
White Blue UV White Blue UV Tray Spots Included Screen Capture Analysis
GelMax DigiColor X Opt Opt X 5 1 X X
BioDoc-It CCD X Opt Opt X 1 1 8” X
MultiDoc-It DigiColor X Opt Opt Opt X 3 1 X
DigiDoc-It DigiColor Opt Opt X 1 1 X
ChromaDoc-It DigiColor X X X
ColonyDoc-It DigiColor X X X 2 X X
PhotoDoc-It DigiColor Opt Opt X 1 1
Basic Imaging Systems
Advanced Imaging Systems
BioImaging Systems Overview
BioImaging Systems Overview and Applications
BioImaging Systems Applications
DNA Gels
Protein Gels
Blue Light Gels
Colony Plates
TLC Gels
Chemiluminescent
Blots
Plants
Multiplex
2D Gels
Macro
In Vivo
Micro
In Vivo
UVP’s Imaging Systems are used for a variety of research applications. The most common applications are listed here. Each
system is coded with the applicable icons. Some applications may require accessories such as converter plates or BioLite.
Opt - Optional
