Manual BioLite MultiSpectral Light Source 4
System Components
Refer to the packing slip and schematic shown below for specific parts and components included with the
BioLite MultiSpectral Light Source.
Specifications
Color Temperature: 3250°K
Bulb Type: 150 Watt Halogen Type EKE
Ferrule Dimension: 0.718 inch (18.2 mm)
Physical Dimensions:
Height 8.75 Inches (22 cm)
Width 7 Inches (18 cm)
Depth 10 Inches (25 cm)
Weight 9 pounds (4 kg)
Power Requirements:
115V 3 Amps max, 50/60 Hz
230V 1.5 Amps max. 50/60 Hz
100V 3 Amps max, 50/60 Hz
Master Power Switch
Light Intensity
Selector Knob
Excitation Filter
Cartridge
Fiber Optic Port and
Cable
