Save 91
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
Note: Do not power off the unit during the save process.
Load Default Settings Click Load Default Settings in the Save section. Figure 71 prompts for
configuration. Refer to Table 45
for more information of the parameters.
Figure 71 Save - Load Default Settings
Click
Load to load the configuration data immediately.
Reboot
the module for the new configuration to take effect.
Note: Do not power off the unit during the load process.
Load Default Settings
using FXS Ports
iAN-02EX also supports the function to restore to default settings using the FXS
ports.
Table 45 Save - Load Default Settings Field Description
Field Description
Default Load all default values that includes all network related fields
Default and Keep Current
Settings
Load all default values while excluding the following network
related fields:
WAN:
■ Wan Type (Static IP/DHCP/PPPoE)
■ IP address
■ Mask address
■ Gateway IP address
LAN:
■ IP address
■ Mask address
■ Gateway IP address
■ DNS1 IP address
■ DNS2 IP address
