82 Chapter 5: Configuration
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Configure the parameters accordingly and click Add o create a new entry.
Select an entry in the
Digit Map Rule table and modify the parameters
accordingly. Click
Modify to confirm the modification.
Select an entry in the
Digit Map Rule table and click Delete to remove the entry.
Configure
Send # and click OK to confirm the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
Hook Flash Click Hook Flash in the VoIP section. Figure 56 prompts for configuration. Refer
to Table 43
for more information of the parameters.
Figure 56 VoIP - Hook Flash
Configure the parameters accordingly. Click
OK to confirm the modification or
click
Cancel to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
Table 43 VoIP - Hook Flash Field Description
Protocol Description
Port Index Port 1 / Port 2
Detection Minimum Time The minimum time to detect hook flash
Default: 200 ms
Detection Maximum Time The maximum time to detect hook flash
Default: 800 ms
