VoIP
81
Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
Digit Map
In contrast to the PSTN digit map, the VOIP digit map allows VOIP calls made
with leading digits and length matching the rules specified to be dialed out
immediately.
Click
Digit Map
in the
VoIP
section. Figure 55 prompts for configuration. Refer
to Table 42
for more information of the parameters.
Figure 55
VoIP - Digit Map
Table 42
VoIP - Digit Map Field Description
Item Description
Port Number Port 1 / Port 2
Leading Digits The prefix or leading digits of the telephone number(s) to be
dialed.
Length The total length of the telephone number. "0" means the length is
not fixed.
Send # Enable: send the digit number at end of dial string is sent to the
SIP-Proxy.
Disable: the digit number at end of dial string is taken as a
terminator.
Default: Enable
