Configure the parameters accordingly. Click OK to confirm the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
Note: The features mentioned above are subject to SIP-Proxy or Soft switch
support; therefore some features may not work when enabled.
Note: For the features to work properly, call flows of the SIP-Proxy and call
agent (softswitch) are needed for customization.
Call Waiting Enable/disable the Call waiting tone
Per Call Deactivate: disactivate call waiting for 1 call
Call Transfer
(CT)
Without
Consultation
CT to another station without prior talking to the receiving station by pressing flash and then dialing
the Feature Code and the end station number
With
Consultation
CT to another station with prior talking to the receiving station by pressing flash and then dialing the
Feature Code and consulting the the end station if the station wants to take the call perform transfer
using the Feature Code.
Three-Way Conference Enable/disable the 3-way conference feature.
Call
Forwarding
Always Enable/disable the Call Forwarding Always.
On - Code used to enable Call Forwarding Always on a per call basis from the PSTN Phone
Off - Code used to disable Call Forwarding Always on a per call basis from the PSTN Phone
Destination - The destination telephone number the call needs to be forwarded if CF is always
turned on
Busy Enable/disable the Call Forwarding Busy.
On - Code used to enable Call Forwarding Busy on a per call basis from the PSTN Phone
Off - Code used to disable Call Forwarding Busy on a per call basis from the PSTN Phone
Destination - The destination telephone number the call needs to be forwarded if Port is busy
No-Answer Enable/disable the Call Forwarding No-Answer.
On - Code used to enable Call Forwarding No-Answer on a per call basis from the PSTN Phone
Off - Code used to disable Call Forwarding No-Answer on a per call basis from the PSTN Phone
Destination - The destination telephone number the call needs to be forwarded if Port is not
answered
Number of Ring - Number of rings after which call is forwarded
DND (Do Not Disturb) Enable/disable the DND feature
Calling Line ID Blocking Enable/disable the Calling Line ID Blocking feature
Per Call Deactivate: disactivate calling line ID blocking for 1 call
Anonymous Call Rejection Enable/disable the Anonymous Call Rejection feature
Priority Reversal Enable/disable the Priority Reversal feature (Currently not available in this release).
Repeat Dialing On Busy Enable/disable the Repeat Dialing On Busy feature (Currently not available in this release)
Repeat time - The time to repeat the dialing
Stop Time - The time to stop repeating dialing
Table 41 VoIP - Call Feature Field Description
Field Description
