Technical data

76 Chapter 5: Configuration
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Save the configuration and Reboot the module for the new configuration to take
effect.
FAX Click Fax in the VoIP section. Figure 51 prompts for configuration. Refer to
Table 38
for more information of the parameters.
Figure 51 VoIP - Fax
Configure the parameters accordingly. Click
OK to confirm the modification or
click
Cancel to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
STUN iAN-02EX supports simple traversal of user datagram protocol (UDP) through
network address translation (STUN). This function allows application to discover
the presence and the types of NATs and firewalls between itself and the public
Internet. It also provides the ability for applications to determine the public IP
address allocated by the NAT.
Click
Stun in the VoIP section. Figure 52 prompts for configuration. Refer to
Table 39
for more information of the parameters.
Table 38 VoIP - FAX Field Description
Item Description
T.38 Fax Enable/disable data-resending mechanism in case of any missing
data during transmission
Default: Enable
T.38 Port The port number for for sending/receiving T.38 packets
Default: 49170
