Technical data

VoIP 75
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
Note:
■ If the country tone is set to North America, the dial tone, busy tone and
ringback tone cannot be modified. If the country tone is set to Custom
Specific Tone, the ring tone (RT1 - RT8) and call waiting tone (WT1 -
WT4) are grayed out.
■ DR1 - DR8 are defined as per Telcordia specification GR-506.
■ DR6 - DR8 are user specific and can be customized.
■ WT1 - WT4 are defined as per Telcordia specification GR-30.
Configure the parameters accordingly. Click OK to confirm the modification or
click
Cancel to discard the modification.
Ring The ringing cadence.
<ontime,offtime (in milliseconds)>
Select the tone from the drop down box for DR1 to DR8. DR1 to
DR5 are preconfigured and DR6 to DR8 can be modified.
■ DR1 <2000, 4000>
■ DR2 <800, 400, 800, 4000>
■ DR3 <400, 200, 400, 200, 800, 4000>
■ DR4 <300, 200, 1000, 200, 300, 4000>
■ DR5 <500, 500>
■ DR6 <2000, 4000>
■ DR7 <2000, 4000>
■ DR8 <2000, 4000>
Dial Tone The dialing tone pattern. Adjustable when the country tone is
Custom Specific Tone.
■ <ontime,offtime (in milliseconds),freq1,freq2 (in Hz)>
Busy Tone The busy tone pattern. Adjustable when the country tone is
Custom Specific Tone.
■ <ontime,offtime (in milliseconds),freq1,freq2 (in Hz)>
Ring back Tone The ringing back tone pattern. Adjustable when the country tone is
Custom Specific Tone.
■ <ontime,offtime (in milliseconds),freq1,freq2 (in Hz)>
Call Waiting Tone The call waiting tone pattern.
■ <ontime,offtime (in milliseconds),freq1,freq2 (in Hz)>
Select the tone from the drop down box for WT1 to WT4:
■ WT1 <300, 10000, 440, 0>
■ WT2 <100, 100, 100, 10000, 440, 0>
■ WT3 <100, 100, 100, 100, 100, 10000, 440, 0>
■ WT4 <100, 100, 300, 100, 100, 10000, 440, 0>
Table 37 VoIP - Tone Field Description
Item Description
