70
Chapter 5: Configuration
iAN-02EX
Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Figure 47
VoIP - SIP
Table 34
VoIP - SIP Field Description
Item Description
Local Port The port number of the SIP stack.
Default: 5060
Proxy Address The IP address of SIP proxy
Default: 0, disable
Proxy Port The port number used by SIP Proxy
Default: 5060
Registrar Address The IP Address of Registration server. Registration Server is often
the same as SIP Proxy Server.
Default: 0, disable
Registrar Port The port number of Registration server.
Default: 5060
Outbound Proxy Address Specifies the IP Address of SIP Outbound Proxy server.
Default: 0, disable
