68
Chapter 5: Configuration
iAN-02EX
Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Figure 45
VoIP - MGCP
Configure the parameters accordingly. Click
OK
to confirm the modification or
click
Cancel
to discard the modification.
Table 32
VoIP - MGCP Field Description
Item Description
Local Port This port number to receive/send data from/to the call agent.
Default: 2427
Call Agent Address The IP address of call agent.
Default: 127.0.0.1
Call Agent Port This port number to receive/send data from/to the VoIP gateway.
Default: 2727
Wild-carded RSIP Enable / disable wild carded RSIP
Default: disable
Endpoint Name Style Style: aaln/#@[ip_addr], mac_addr/#@[ip_addr],
aaln/#@mac_addr, aaln/#@domain_name.
Default: aaln/#@[ip_addr]
Gateway Domain The domain name of the gateway
Default: domain.net
Expires The period that the VoIP gateway sends keeping-alive message to
the call agent. This is check the connection status in case the VoIP
gateway is accidentally disconnected from the call agent.
Default: 150 seconds.
