VoIP
67
Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
■
Speed Dial
■
Call Features
■
Digit Map
■
Hook Flash
■
Jitter Buffer
Protocol
Click
Protocol
in the
VoIP
section. Figure 44 prompts for configuration. Refer to
Table 31
for more information of the parameters.
Figure 44
VoIP - Protocol
Configure the parameters accordingly. Click
OK
to confirm the modification or
click
Cancel
to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
MGCP
Click
MGCP
in the
VoIP
section. Figure 45 prompts for configuration. Refer to
Table 32
for more information of the parameters.
Table 31
VoIP - Protocol Field Description
Field Description
MGCP MGCP voice signaling protocol
SIP SIP voice signaling protocol
Default.
