66
Chapter 5: Configuration
iAN-02EX
Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Figure 43
EMS - SNMP Community
Configure the parameters accordingly. Click
OK
to confirm the modification or
click
Cancel
to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
VoIP
The VoIP configuration contains the following sections:
■
Protocol
■
MGCP
■
User
■
SIP
■
Audio Config
■
RTP
■
Tone
■
FAX
■
STUN
Table 30
EMS - SNMP Trap Target Field Description
Field Description
Trap Disable / enable SNMP trap
Default: Off
Target 1~ 4 Specify the IP address to which the traps of the VOIP
Port 1~ 4 Specify the Port to which the traps of the VOIP Gateway will be
sent
