64
Chapter 5: Configuration
iAN-02EX
Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Figure 41
EMS - EMS
Configure the parameters accordingly. Click
OK
to confirm the modification or
click
Cancel
to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
SNMP Community
Click
SNMP Community
in the
EMS
section. Figure 42 prompts for
configuration. Refer to Table 29
for more information of the parameters.
Table 28
EMS - EMS Field Description
Item Description
Server Address The IP Address of the EMS server
0: Disable syslog server
Server Port The port number of the EMS server
Default: 63030
Community The community used by the EMS server
Value range: Public community / Private community
Default: private
Expires The period that the VoIP Gateway sends keeping-alive message
to EMS server. This is to check the connection status in case the
VoIP Gateway is accidentally disconnected from the EMS server.
Default: 3600 seconds
