Element Management System (EMS)
63
Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
Figure 40
Syslog - Syslog
Configure the parameters accordingly. Click
OK
to confirm the modification or
click
Cancel
to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
Element Management
System (EMS)
The EMS configuration contains the following sections:
■
EMS
■
SNMP Community
■
SNMP Trap Target
////////////////////////////////
EMS
Click
EMS
in the
EMS
section. Figure 41 prompts for configuration. Refer to
Table 28
for more information of the parameters.
Table 27
Syslog - Syslog Field Description
Item Description
Server Address The IP address of syslog server.
Default: 0, disable syslog server
Server Port The port number of syslog server.
Default: 514
Level-3/Level-4 Debug Disable / enable sending level-3/level-4 debug messages to
syslog server
Default: Disable
