62 Chapter 5: Configuration
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Configure the parameters accordingly. Click OK to confirm the modification or
click
Cancel to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
Refer to Appendix B
for more information of provision procedures and rules.
Syslog This iAN-02EX VoIP Gateway supports sending system log (sending UDP
packets via Syslog port (514)) and keeping log messages in Log server.
Syslog Click Syslog in the Syslog section. Figure 40 prompts for configuration. Refer
to Table 27
for more information of the parameters.
HTTP Server Address The IP address or URL of the HTTP provision server.
Default: devicecfg.private.net/devicecfg/utstarcom/config
HTTP Server Port The port numbers of the HTTP provision server.
Default: 80
Group The group the VoIP gateway belongs to. The maximum length is
64.
Default: 0
Expires The period (in seconds) that the VoIP gateway retrieves
configuration files from Provision server. The valid period for this
device's IP address assigned by DHCP server or PPPoE server.
Enter the value provided by user's ISP.
Default: 3600 seconds
TFTP Upgrade Server
Address
The IP address or URL of the TFTP upgrade server.
Default: devicecfg.private.net/firmware/utstarcom
TFTP Upgrade Server Port The port numbers of the TFTP upgrade server.
Default: 69
HTTP Upgrade Server
Address
The IP address or URL of the HTTP upgrade server.
Default: devicecfg.private.net/firmware/utstarcom
HTTP Upgrade Server Port The port numbers of the HTTP upgrade server.
Default: 80
Sync Check Enable/Disable SIP proxy to trigger sync check event. When
enabled, ATA reboots and starts the default provisioning process if
SIP proxy triggers sync check event.
Default: Disable
Note: Authentication option will be supported in future release.
Table 26 Provision - Provision Field Description
Item Description
