Technical data

Provision 61
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
and the existing local setting. If the downloaded setting parameter is newer, then
it will overwrite the existing local setting parameters.
Provision Click Provision in the Provision section. Figure 39 prompts for configuration.
Refer to Table 26
for more information of the parameters.
Figure 39 Provision - Provision
Table 26 Provision - Provision Field Description
Item Description
Provision Priority The priority of the provision server.
Default: TFTP First
TFTP Server Address The IP address or URL of the TFTP provision server.
Default: devicecfg.private.net/devicecfg/utstarcom/config
TFTP Server Port The port numbers of the TFTP provision server. When enabled,
port 1 is required and port 2 & 3 are optional. When specified, port
2 is used if port 1 is not available. Port 3 is used if port 1 and port 2
are not available.
Default: 69, 100, 200
