54 Chapter 5: Configuration
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
Enter the corresponding ID number listed in the table and click Delete to remove
the entry.
Save
the configuration and Reboot the module for the new configuration to take
effect.
DMZ DMZ (De-Militarized Zone) is a firewall feature governing real-time information
exchanged through the VOIP gateway device. DMZ allows a single computer on
the LAN side network to expose all of its ports to the Internet, which means the
exposed computer is no longer behind the firewall. When a packet enters the
VOIP gateway, the packet is transferred to the DMZ if it is not filtered nor
port-forwarded.
Click
DMZ in the Gateway Mode Settings section. Figure 32 prompts for
configuration. Refer to Table 19
for more information of the parameters.
Figure 32 Gateway Mode Settings - DMZ
Configure the parameters accordingly. Click
OK to confirm the modification or
click
Cancel to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
QoS The QoS configuration contains the following sections:
■ QoS Configuration
Table 19 Gateway Mode Settings - DMZ Field Description
Field Description
DMZ Off: Disable DMZ. Default.
On: Enable DMZ
DMZ IP Address The IP address of the DMZ
