Gateway Mode Settings 51
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
Configure the parameters accordingly. Click OK to confirm the modification or
click
Cancel to discard the modification.
Save
the configuration and Reboot the module for the new configuration to take
effect.
Port Forwarding A NAPT application creates a firewall between LAN and WAN. A firewall keeps
unwanted traffic away from user computers in the LAN. A tunnel can be created
through user firewall so that a distant server on the Internet can communicate
with one of the user computers in the LAN via a single port.
Table 16 Gateway Mode Settings - LAN Configuration Field Description
Item Description
LAN IP Configuration
LAN IP The LAN IP address
Default: 172.25.25.1
LAN Netmask The LAN netmask
Default: 255.255.255.0
LAN Gateway The LAN gateway IP address.
Default: 172.25.25.1
DHCP Configuration
Status To enable/disable DHCP server's dynamic IP address
assignment.
Default: Enable
Mode To automatically obtain or manually assign the DNS server
address.
Default: Auto
Pool Start IP The starting IP address of the IP address pool.
Default: 172.25.25.1
Pool End IP The ending IP address of the IP address pool.
Default: 172.25.25.21
Default Gateway The default network gateway IP address.
Default: 172.25.25.1
DNS 1 The IP address of domain name server 1. Configurable with
Manual mode.
Default: 172.25.25.1
DNS 2 The IP address of domain name server 2. Configurable with
Manual mode.
Default: 0.0.0.0
Domain The domain name.
Default: .com
Lease Time The time duration for which the settings will be in effect.
Default: 86400 seconds
