WAN
45
Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
Figure 24
WAN - WAN IP
Configure the parameters accordingly. Click
OK
to confirm the modification or
click
Cancel
to discard the modification.
Table 11
WAN - WAN IP Field Description
Field Description
Static IP Address To configure a static IP address.
IP The static IP address of the iAN-02EX VoIP gateway
Default: 171.25.25.1
Mask The subnet mask of the iAN-02EX VoIP gateway
Default: 255.255.255.0
Gateway The network gateway address of the iAN-02EX VoIP gateway
Default: 172.25.25.1
DNS 1 The IP address of domain name server 1.
Default: 192.168.100.1
DNS 2 The IP address of domain name server 2.
Default: 192.168.100.2
DHCP To obtain an IP address through DHCP.
Default connection mode.
Host Name The name of the DHCP host.
Default: 0
PPPoE To obtain an IP address through PPPoE.
