Web Browser
33
Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
4
Select the radio button for Using the following IP address in Figure 12. Set IP
address as
172.25.25.100
and set Subnet mask as
255.255.255.0
. Click
OK
to
confirm the settings and return to Figure 11
. Click
OK
again to exit.
Figure 12
Internet Protocol (TCP/IP) Properties - Bridge Mode
The Configuration for Windows 2000/XP is now completed. Refer to Web
Browser for configuration procedures via web browser.
Web Browser
Once the TCP/IP of the PC is properly configured, please proceed the following
steps:
1
Start a web browser window.
2
Enter the default IP address,
172.25.25.1
, of this device in the address box to
access the web configuration menu.
