26
A
PPENDIX
: T
ECHNICAL
S
PECIFICATION
iAN-02EX
Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
VOICE ALGORITHMS G.711 (A-law or mLaw), G.723.1 (6.3 kbps, 5.3 kbps)
G.726 (16/24/32/40 kbps), G.729 a/b
Line Echo Cancellation [32ms (min) ~ 128ms (max)]
Adaptive Jitter Buffer (Up to 90ms jitter)
Asymmetrical Codes (Allows upstream and downstream to use different codecs)
AGC (Auto Gain Control), AEC (Auto Echo Cancellation)
Voice Activity Detection (VAD) and Comfort Noise (CNG)
Echo Cancellation G.165/G.168 and Attenuation and Gain Adjustment
SLIC SPECIFICATION Signaling: Loop Start and Polarity Reversal
Ringing source: Internal, 5 REN (Indoor Loops)
Loop current: 20 mA
UNIVERSAL POWER ADAPTER AC adapter: 12 VDC (120 VAC / 60 Hz or 220 VAC / 50 Hz input)
Power consumption: 6.0 watts (typical)
UNIT DIMENSIONS W x D x H: 190mm x 130mm x 30mm
Mounting Horizontal or Vertical
WEIGHT 1.9 lbs (Approx.)
ENVIRONMENTAL
Operating (System Ambient) 0° C to 40° C -197 to 7000 feet
Humidity 8% to 95% non-condensing
Shipping & Storage -25° C to 65° C, Low humidity for Low temperatures,
90% at 45° C and 30% at 65° C
REGULATORY COMPLIANCE CE, FCC part 15 Class B, UL certified
Table 4
Technical Specifications
Item Specifications
