25
Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
LEDs Ethernet LAN: 10/100M, Link/Activity
WAN: 10/100M, Link/Activity
VoIP Ready
LINE1: Activity
LINE2: Activity
Power
SUPPORTED SPECIFICATION AND APPLICATIONS
DATA NETWORKING ARP Address Resolution Protocol
MAC Address (IEEE 802.3)
TCP (RFC 793), UDP (RFC 768)
DHCP Client/Server (RFC 2131)
IPV4 (RFC 791/RFC 1883)
NAT (RFC 3022)
STUN (RFC 3489)
NTP (RFC 1305)
ICMP (RFC 792)
PPPoE (RFC-2516)
MD5 (RFC 1321)
Type of Service (TOS) (RFC 1349)
DiffServ (RFC 2475)
RTP (RFC 1889/1890), RTCP (RFC 1890)
TFTP (RFC 1350), HTTP Client/Server (RFC 2131)
Https factory installed certificate
ITU-T T.30 Fax mode, ITU-T T.38 Fax Mode
PPPoE (RFC 2516)
ITU-T T.30 Fax Mode
ITU-T T.38 Fax Mode
CALL CONTROL / VOIP FEATURES SIP (RFC 3261), MGCP and H.323
SIP-Event (RFC-3265)
SIP Proxy redundancy A-Records, DNS-SRV
RTCP Attribute in SDP (RFC 3605)
Wild-Card RSIP definition.
Configurable End-Point-Styling.
Heart Beat (MGCP) functionality for Call Agents.
Disable/Enable Registrar
RTP/RTCP (RFC 3550)
RTP Payload for DTMF Digits, Telephony Tones and Signals (RFC 2833)
Tone Generation (GR-506) and Custom definable.
Call ID (Bell Core GR-30, DTMF)
Table 4
Technical Specifications
Item Specifications
