Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
3
T
ECHNICAL
S
PECIFICATION
Table 4
Technical Specifications
Item Specifications
MANAGEMENT AND PROVISIONING Automatic System firmware/Configuration download via TFTP/HTTP servers
Authentication based on user name, password and login ID
Flexibility to use TFTP only, HTTP only or both TFTP/HTTP
Configurable TFTP/ HTTP priority order selection
TFTP port enable/disable, TFTP port hunting up to 3 ports
Configurable TFTP/HTTP feature with enable/disable flags
URL based entry for TFTP/HTTP provisioning
3 Optional config for provisioning
Encryption utility available for Config file for download
Auto sensing of TFTP port and disable download function, if Port unavailable
2 Logins for Maintenance with Online debug capability with 4 debug levels
System Telnet and CLI interface for maintenance operations
EMS (Element Management System) support based on SNMP traps
Reset to factory default via digit map.
Message Log on to Syslog server
Enable/Disable WAN provisioning
