152
A
PPENDIX
E: U
PGRADE
P
ROCEDURE
iAN-02EX
Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
■
Connect PC to LAN side
■
Please verify using ipconfig command on the PC connected to the LAN side
■
Connect ATA using ip-address 172.25.25.1
■
ATA on the LAN side should get ip-address 172.25.25.2
■
Login=
supervisor
password=
utstar
Upgrade Notes
LAN side ip-address
change
The upgrade from V1.8.2.2a (Generic) units to V1.8.2.19a will change the
default LAN side ip-address from 192.168.0.x to 172.25.25.1. Hence after
upgrade please make sure to connect to 172.25.25.1 to gain access to the ATA.
WAN side Static
ip-address
configuration.
On doing load default user will need to configure the IP-Address of the WAN
side if static ip-address was used previously. Configuration of Static WAN
ip-address can be done using the GUI us the WANIP tab.
If DHCP option is used for the acquiring WAN-Side ip-address behavior will be
the same as before upgrade.
