Technical data

Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
E
U PGRADE P ROCEDURE
Upgrade Procedure Follow the procedures below to upgrade Generic units from V1.8.2.2a or interim
Generic release to V1.8.2.19a.
1 Step1
■ Connect PC to LAN side.
■ Connect ATA using ip-address 192.168.0.1
■ Please verify using ipconfig command on the PC connected to the LAN side.
■ The ATA on the LAN side should get ip-address 192.268.0.2
■ Login=supervisor password=utstar
■ System screen should be available on the PC connected to the LAN side.
■ Display should show V1.8.2.2a [Factory shipped generic version]
2 Step2
■ Go to firmware Upgrade tab and select firmware [V1.8.2.19a].
■ ATA will read the file and VoIP, Line1 and Line2 LED's will flicker after 2
minutes.
■ Once done ATA will reboot.
3 Step3
■ Wait for a while and check the LAN LED on the ATA.
■ Connect PC to LAN side.
■ Connect ATA using ip-address 192.168.0.1
■ Login= supervisor password= utstar
4
Step4
■ Go to Load Default Settings tab.
■ Select radio button Default settings
■ ATA will load the default and the Reboot screen will appear.
■ Select reboot, ATA will now reboot with the new default values.
5 Step5
