144 A PPENDIX D: I AN-02EX SNMP MIB R EFERENCE
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
rgHistoryAlarmTable This table contains information about specific history alarm.
Indexed by:
■ rgHistoryAlarmIndex
rgCallHistoryTxOctets
1.3.6.1.4.1.4684.5.4.5.1.1.13
read-only current
The total number of payload octets (not including header or
padding) transmitted in RTP data packets during a call in
the Call History.
Integer32
rgCallHistoryRxOctets
1.3.6.1.4.1.4684.5.4.5.1.1.14
read-only current
The total number of payload octets (not including header or
padding) received in RTP data packets during a call in the
Call History.
Integer32
rgCallHistoryCODEC
1.3.6.1.4.1.4684.5.4.5.1.1.15
read-only current
The CODEC(payload) type of a call in the Call History. DisplayString (0..255)
rgCallHistoryPacketPeriod
1.3.6.1.4.1.4684.5.4.5.1.1.16
read-only current
The packet period(CODEC rate) of a call in the CallHistory. INTEGER (1..65536)
rgCallHistoryPacketLoss
1.3.6.1.4.1.4684.5.4.5.1.1.17
read-only current
The total packets loss during a call in the Call History. Integer32
Table 53 rg Call History Table
Node / OID Description Settings
Table 54 rg History AlarmTable
Node / OID Description Settings
rgHistoryAlarmIndex
1.3.6.1.4.1.4684.5.4.10.3.1.1
not-accessible current
table index of Current Alarm Table INTEGER (1..10)
rgHistoryAlarmTime
1.3.6.1.4.1.4684.5.4.10.3.1.2
read-only current
Current system time in GMT, it is represented as seconds
since 1970(YY):1(MM):1(DD):0(HH):0(MM):0(SS). For
example, if the dateTime is 86400, it means the system
time is 1970:1:2:0:0:0:
INTEGER
rgHistoryAlarmObject
1.3.6.1.4.1.4684.5.4.10.3.1.3
read-only current
The interface object with current alarm 0 - system 1 - 16
VOIP endpoint
INTEGER (0..16)
rgHistoryAlarmCause
1.3.6.1.4.1.4684.5.4.10.3.1.4
read-only current
The history alarm cause ProbableCause
