Technical data

rgCallHistoryTable 143
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
Indexed by:
■ rgCallHistoryIndex
Table 53 rg Call History Table
Node / OID Description Settings
rgCallHistoryIndex
1.3.6.1.4.1.4684.5.4.5.1.1.1
not-accessible current
Index variable to access the RgCallHistoryEntry objects of
the rgCallHistoryTable.
INTEGER (1..500)
rgCallHistoryPort
1.3.6.1.4.1.4684.5.4.5.1.1.2
read-only current
The attributed port number of the Call History. INTEGER (1..65536)
rgCallHostoryDirection
1.3.6.1.4.1.4684.5.4.5.1.1.3
read-only current
The direction of the call in the Call history. The (1)send
indicates that this call is a outgoing call and the (2)recv
indicates that this call is a incoming call.
INTEGER
■ send(1)
■ recv(2)
rgCallHistoryCallingNumber
1.3.6.1.4.1.4684.5.4.5.1.1.4
read-only current
The phone number of Calling party in the Call History. DisplayString (0..255)
rgCallHistoryCalledNumber
1.3.6.1.4.1.4684.5.4.5.1.1.5
read-only current
The phone number of Called party in the Call History. DisplayString (0..255)
rgCallHistoryStart
1.3.6.1.4.1.4684.5.4.5.1.1.6
read-only current
The start time of a call in the Call History. DisplayString (0..255)
rgCallHistoryEnd
1.3.6.1.4.1.4684.5.4.5.1.1.7
read-only current
The end time of a call in the Call History. DisplayString (0..255)
rgCallHistoryDur
1.3.6.1.4.1.4684.5.4.5.1.1.8
read-only current
The duration time of a call in the Call History. DisplayString (0..255)
rgCallHistoryRemIp
1.3.6.1.4.1.4684.5.4.5.1.1.9
read-only current
The remote IP address of a call in the Call History. IpAddress
rgCallHistoryRemPort
1.3.6.1.4.1.4684.5.4.5.1.1.10
read-only current
The remote port number of a call in the Call History. INTEGER (1..65536)
rgCallHistoryTxPackets
1.3.6.1.4.1.4684.5.4.5.1.1.11
read-only current
The total number of RTP packets transmitted during a call
in the Call History.
Integer32
rgCallHistoryRxPackets
1.3.6.1.4.1.4684.5.4.5.1.1.12
read-only current
The total number of RTP packets received during a call in
the Call History.
Integer32
