Technical data

systemInformationTable 139
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
systemInformationTab
le
Indexed by:
■ systemInformationIndex
notificationSeq
1.3.6.1.4.1.4684.5.4.20.1.0
accessible-for-notify current
Notification sequence number Integer32
notificationClass
1.3.6.1.4.1.4684.5.4.20.2.0
accessible-for-notify current
Notification class type INTEGER
■ fault(4)
■ restore(5)
■ event(6)
notificationPortIdx
1.3.6.1.4.1.4684.5.4.20.3.0
accessible-for-notify current
Notification port index number Integer32
notificationSoftSwitchIdx
1.3.6.1.4.1.4684.5.4.20.4.0
accessible-for-notify current
Notification soft switch number Integer32
Table 47 MIB Scalar Objects Table
Node / OID Description Settings
Table 48 System Information Table
Node / OID Description Settings
systemInformationIndex
1.3.6.1.4.1.4684.5.1.1.1.1.1.1.1.1
read-only current
Table entry index value INTEGER
tFTPServerIP
1.3.6.1.4.1.4684.5.1.1.1.1.1.1.1.41
read-write current
The ip address of TFTP server for software download IpAddress
tFTPFileName
1.3.6.1.4.1.4684.5.1.1.1.1.1.1.1.42
read-write current
file name to be downloaded via TFTP DisplayString (0..255)
tFTPOperation
1.3.6.1.4.1.4684.5.1.1.1.1.1.1.1.43
read-write current
Doing download software with file name as tFTPFileName
for software upgrade.
INTEGER
■ off(0)
■ swDownload(1)
default = off
tFTPResult
1.3.6.1.4.1.4684.5.1.1.1.1.1.1.1.44
read-only current
Tftp download result. INTEGER
■ fail(0)
■ success(1)
default = fail
