138 A PPENDIX D: I AN-02EX SNMP MIB R EFERENCE
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
rgEmsSnmpTrapCommunity
1.3.6.1.4.1.4684.5.4.8.3.0
read-write current
The snmp trap community name of system. DisplayString (0..255)
rgEmsSnmpTrapIP1
1.3.6.1.4.1.4684.5.4.8.4.0
read-write current
The network IP address of SNMP server for receiving traps. IpAddress
rgEmsSnmpTrapIP2
1.3.6.1.4.1.4684.5.4.8.5.0
read-write current
The network IP address of SNMP server for receiving traps. IpAddress
rgEmsSnmpTrapIP3
1.3.6.1.4.1.4684.5.4.8.6.0
read-write current
The network IP address of SNMP server for receiving traps. IpAddress
rgEmsSnmpTrapIP4
1.3.6.1.4.1.4684.5.4.8.7.0
read-write current
The network IP address of SNMP server for receiving traps. IpAddress
rgEmsSnmpTrapPort1
1.3.6.1.4.1.4684.5.4.8.8.0
read-write current
The port number of SNMP server for receiving traps. INTEGER (1..65536)
rgEmsSnmpTrapPort2
1.3.6.1.4.1.4684.5.4.8.9.0
read-write current
The port number of SNMP server for receiving traps. INTEGER (1..65536)
rgEmsSnmpTrapPort3
1.3.6.1.4.1.4684.5.4.8.10.0
read-write current
The port number of SNMP server for receiving traps. INTEGER (1..65536)
rgEmsSnmpTrapPort4
1.3.6.1.4.1.4684.5.4.8.11.0
read-write current
The port number of SNMP server for receiving traps. INTEGER (1..65536)
rgEmsExpires
1.3.6.1.4.1.4684.5.4.8.12.0
read-write current
The period(in seconds) of sending IP inform message to
EMS server.
Integer32
rgCurrentAlarmReset
1.3.6.1.4.1.4684.5.4.9.2.0
read-write current
Reset current alarm table. INTEGER
■ trigger(1)
■ normal(2)
rgHistoryAlarmNum
1.3.6.1.4.1.4684.5.4.10.1.0
read-only current
The number of entries in history alarm table INTEGER
rgHistoryAlarmReset
1.3.6.1.4.1.4684.5.4.10.2.0
read-write current
Reset history alarm table. INTEGER
■ trigger(1)
■ normal(2)
Table 47 MIB Scalar Objects Table
Node / OID Description Settings
