Technical data

MIB Scalar Objects 137
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
rgMgtNtpExpires
1.3.6.1.4.1.4684.5.4.7.17.0
read-write current
The period(in seconds) of retrieving time from NTP server. Integer32
rgMgtNtpSync
1.3.6.1.4.1.4684.5.4.7.18.0
read-write current
Synchronize local time with ntp server. INTEGER
■ on(1)
■ off(2)
default = off
rgMgtSyslogServerAddress
1.3.6.1.4.1.4684.5.4.7.19.0
read-write current
The network IP address of the syslog server. IpAddress
rgMgtSyslogServerPort
1.3.6.1.4.1.4684.5.4.7.20.0
read-write current
The port number of the syslog server. INTEGER (1..65536)
rgMgtVoipStunNatAddress
1.3.6.1.4.1.4684.5.4.7.21.0
read-write current
The network IP address of the NAT firewall. Should be
specified if this device is located behind a NAT firewall. The
NAT firewall should also activate port mapping or DMZ
funtions to forward incoming voip signaling packet and RTP
packets to this device. Make sure the STUN(Simple
Traversal of User Datagram) server address is 0 if you want
to specify nataddress by yourself. If the IP address of the
NAT firewall is unknown, specify STUN server to determine
it automatically.
IpAddress
rgMgtVoipStunServerIp
1.3.6.1.4.1.4684.5.4.7.22.0
read-write current
The network IP address of STUN(Simple Traversal of User
Datagram) server. It is used to detecting the IP address of
the NAT firewall. If this function is enabled, after detecting
the IP address of the NAT firewall, 'nataddress' will be
changed automatically.
IpAddress
rgMgtVoipStunServerPort
1.3.6.1.4.1.4684.5.4.7.23.0
read-write current
The port number of the STUN server. INTEGER (1..65536)
rgMgtVoipStunLocalport
1.3.6.1.4.1.4684.5.4.7.24.0
read-write current
The local listening port number of the STUN client. INTEGER (1..65536)
rgMgtVoipStunExpires
1.3.6.1.4.1.4684.5.4.7.25.0
read-write current
The period(in seconds) of sending STUN message to STUN
server.
Integer32
rgEmsSnmpGetCommunity
1.3.6.1.4.1.4684.5.4.8.1.0
read-write current
The snmp get community name of system. DisplayString (0..255)
rgEmsSnmpSetCommunity
1.3.6.1.4.1.4684.5.4.8.2.0
read-write current
The snmp set community name of system. DisplayString (0..255)
Table 47 MIB Scalar Objects Table
Node / OID Description Settings
